Porsche eBike Cross 2nd Gen.

$9,500.00excl. Tax
Sold by Porsche Design of America, Inc.
Porsche eBike developed in cooperation with Rotwild with frame design created by Studio F. A. Porsche Maximum e-performance thanks to the powerful Shimano motor and chassis components from Fox.
Color: Dark Grey
Size: -SMLEbike Size Chart
Notify me
Add to wishlist
Unfortunately, this product is currently not in stock.Please notify me when it becomes available again.

Product details

Description

Performance on two wheels: the Porsche eBike in cooperation with Rotwild with a full-suspension carbon frame, designed by Studio F. A. Porsche, impresses with its design and performance. It combines sporty, elegant design with powerful drive performance: the latest generation of the powerful Shimano drive unit consisting of motor, battery and electronic gears ensures effortless acceleration. The Magura disc brakes and upside-down suspension fork, along with the rear shock absorber from Fox, ensure effortless and quick braking and a high level of riding comfort. The brake hydraulics from Magura (MCI) integrated into the handlebar give the cockpit a clean look. The robust wheels from Crankbrothers ensure a stable and durable driving experience, on- and off-road.

Battery:

630 Wh capacity [size S: 504 Wh].Range [approx.]: 125km [ECO]/100km [TRAIL]/75km [BOOST].Charging: 50% in about 2 ½ hours, from 0 to 100% in about 6 hours.Battery range: these are approximate values. The actual range depends on many different factors.

Suitable frame size based on body height in metres:

Frame size S: body height 1.56-1.70 m; wheel size 27.5 inch.Frame size M: Body height 1.68-1.82 m; wheel size 29 inch.Frame size L: body size 1.80-1.94 m; wheel size 29 inch.

Highlights:

Full-suspension carbon frame with 100 mm spring deflection designed by Studio F. A. Porsche.SHIMANO EP8 motor with max. 85 Nm torque.Electronic SHIMANO XT DI2 11-speed rear derailleur.MAGURA MCi disc brakes with 4-piston front and rear brake callipers.FOX Float DPS rear shock.Light integration in stem and seat post from SUPERNOVA.Aero seat post with integrated rear light and deceleration signal.

Technical specification:

Suspension:

Rear shock: Fox Float DPSFork: Magura boltron 100mm (20x110mm)

Cockpit:

Headset: Acros RW750 1,5“Handlebar: Ergotec flatbar MCI 31,8mmStem: Porsche Custom 60mm (SP-Connect-Schnittstelle incl.)Seatpost: Aero Seatpost w/rear light (Supernova TL3 rear w/ brake light)Saddle: Ergon SM 10 Pro CarbonGrips: Ergon GA20 Black w/supernova light clamp

E-Bike-System:

Display: Shimano SC-EN800w/31.8mm clampMotor: Shimano DU-EP800 (25km/h / 20mp/h)Battery: Shimano BT-E8036 630 Wh (Größe S: BT-E8035 504Wh)

Drivetrain:

Crankset: Shimano FC-EM900 (160mm) 165mmChainguide: Shimano SM-CRE80-B, 36TShift lever: Shimano Di2 SW-E7000-RDerailleur: Shimano XT Di2 RD-M8050 11-SpeedChain: Shimano XT CN-HG700-11Cassette: Shimano XT CS-M8000-11 (11-46T)

Brakes:

Brake: Magura MCI (4-piston front and rear)Brake disc: Magura MDR-P6-bolt (203/180mm)

Wheels:

Wheelset: Crankbrothers Iodine 2 29* (27.5*)Tires: Continental Race King 29* (27,5*) 2,2*

Accessories:

Pedals: Crankbrothers Stamp 2Light front: Supernova M99 Mini Pro 25Light rear: Supernova TL3 rear

Item no.: WAP065EBS0P00L

More Details
Dimensions: 1900 mm x 770 mm x 1050 mm
Material and care instructions
Material: Carbon fiber, aluminum, plastic, others
Care Instructions: Regular cleaning of all components with a light water jet or a soft, wet sponge. Warning: Use of high pressure cleaners may cause damage to seals and bearings. Lubricate chain after each cleaning. Do not immerse in grease-dissolving detergent. Take care not to drip oil on brake discs.
Downloads
WARNING

Components of some products, including timepieces, eyewear, sandals, gaming chair, seating tuns, hardcases, charging hardware, automotive care and cleaning supplies can expose you to chemicals including Bisphenol A (BPA), Diisononyl Phthalate, Lead and Nickel which are known to the State of California to cause cancer, reproductive harm or birth defects. For more information visit www.P65Warnings.ca.gov

Porsche eBike Cross 2nd Gen.
General
Dimensions
1900 mm x 770 mm x 1050 mm
Permissible max. weight
-
Wheels
Wheel size
29* (27.5*) 2,3*/2,2*
Wheel set
Crankbrothers Synthesis Enduro Alloy 29* (27,5*)
Tires
Continental Cross King 29* (27.5*) 2,3*/2,2*
E-Bike system
Motor
Shimano DU-EP800 (25km/h / 20mp/h)
Battery
Shimano BT-E8035-L 504 Wh (S: BT-8035 504 Wh)
Battery capacity
504 Wh (S: BT-8035 504 Wh)
Display
Shimano SC-EM800w/35mm clamp
Suspension
Rear shock
Fox Float DPS
Fork
Fox 34 Float Performance 120mm, Boost
Cockpit
Headset
Acros RW750 1,5“
Handlebar
B280 Riser 35mm 740mm
Stem
S140 STEM-35 50MM
Seat post
Crankbrothers Highline 3 150mm
Saddle
Ergon SM Comp
Grips
Ergon GA20 Black
Lights
-
Drivetrain
Crankset
Shimano FC-E8150(160mm) 165mm
Chain guide
Shimano SM-CRE80-B, 36T
Shift lever
Shimano XT SL-M8100-R 12-speed I-Spec
Derailleur
Shimano XT RD-M8100 12-Speed Shadow+
Chain
Shimano SLX CN-HG7100-12
Cassette
Shimano CS-M6100-12 (10-51T)
Brakes
Brake
Magura MT Trail (4-piston front/2-piston rear)
Brake disk
Magura MDR-P6-bolt (203/180mm)
Accessories
Pedals
Crankbrothers stamp 2
